Power Data
* Power supply: 3 x 400Vac….480Vac 50/60Hz
* Motor power ratings from 11kW (7.5Hp) to 27kW (20Hp), @ 400Vac
* Overload: 183% for 10 seconds
* Motor type: Synchronous

EMC & Mark Compliances:
CE Mark

Main Features

• Integrated Regenerative Unit
• Unitary power factor (cosphi)
• Low harmonic distortion of input current <4%
• Multispeed control
• Short floor management
• Flexible ramp management
• Management of TTL incremental digital encoder
• Management of SinCos absolute encoder
• “Space vector” modulation reduces noise levels to a minimum.
• Motor parameters self tuning

Product Set-Up
The configuration set-up can be done by the following:

• Integrated programming keypad
• PC with Graphical User Interface GF-eXpress

Easy and safe start-up
Thanks to the User-friendly menu the configuration of the drive is fast and intuitive.
